Spark plug NGK CR6HSA, 2983
Prices incl. VAT plus shipping costs
IN STOCK - Delivery time 1-3 working days
- Item no: 160660
- EAN: 0087295129838
- Manufacturer: NGK
- Manufacturer no.: 2983
DESCRIPTION:
The spark plug consists of a metal core encased in a ceramic insulator. This metal core is in turn surrounded by a metal sheath. The metal jacket consists of a thread which is turned into the cylinder head. There has hardly been any change in this basic design of the spark plug over the last 50 years.
With a selection of over 1000 different spark plug types, NGK SPARK PLUGS is the clear market leader in the ignition segment. There are justified reasons for this market position: On the one hand, the outstanding quality is impressive, on the other hand NGK is constantly researching and optimising its products. One can therefore be sure that NGK products are always at the cutting edge of technology. The spark plugs are uniquely designed to guarantee the best possible performance. There is a wide range of different thermal characteristics for a high thermal load.
Spark plugs in top quality and at a reasonable price? Fast shipping and over 10,000 other products. Of course with ZS2Radteile.
TECHNICAL DATA:
- TYPE CR6HSA
- manufacturer no. 2983
- interference suppressed 5 kOhm
- Width across flats SW16 (16.0 mm)
- Thread M10 (10.0 mm)
- Thread length 12,7 mm
- Electrode distance 0.7 mm
- Contact ignition cable M4- thread
SCOPE OF DELIVERY:
✔ 1x spark plug CR6HSA from NGK
COMPARABLE WITH:
AC Delco S102F
Autolite 2796, 4194
Bosch 0242055501, UR3AC, UR4AS
Brisk NAR15YS
Champion P-RZ9HC, P-Z9HC, RZ98C, Z9Y
Champion pcs 808
Denso 4004, IUF22, U20FSR-L, U20FSR-U, U20FSRU
Denso pcs 4004
General Motors 5613467
Honda 98056-56717-00, 98056-56718, 98056-5671R-00, 98056-56726
Kawasaki 920701153, E920701153, J4520U20FSRU
NGK pcs 2983
Prestolite 10E2,10E3
Suzuki 09482-00406, 09482-00407
Tacti V91104004
Torch A6RTC
Toyota 90098-70023
Yamaha 90793-20132, 94700-00372, 94700-00879, 94701 00372, 94701-00372, 9470100372
Product type: | Spark plug |
Sealing: | Flat tight fit |
Replacement part number: | Champion Z9Y, Denso IUF22, Denso U20FSR-L, Denso 4, BOSCH UR4AS, Champion P-RZ9HC, Champion RZ98C, BOSCH 0242055501, BOSCH UR3AC |
Number of earth electrodes: | 1 |
Thermal value: | 6 |
suppressed?: | Yes, 5 kOhm |
Tuning & Styling Part: | No |
Thread diameter: | 10 mm |
Electrode gap: | 0.7 mm |
Vintage part: | No |
Spark plug type: | CR6HSA |
Universal compatibility: | Yes |
Quantity per pack: | 1 |
Spark position: | 1.65 mm |
Contact ignition cable: | Connection version M4 |
GTIN: | 0087295129838 |
Scope of delivery: | 1x spark plug NGK CR6HSA |
Manufacturer number: | 2983 |
Country and region of manufacture: | Japan |
Reference number(s) OE: | Bosch 0242055501 Bosch UR3AC Bosch UR4AS, Champion P-RZ9HC Champion P-Z9HC Champion, 4004 Denso IUF22 Denso U20FSR-L Denso, U20FSR-U,Denso U20FSRU ,Denso, stk 4004 ,NGK stk 2983, 2983, RZ98C Champion Z9Y Champion stk 808 Denso |
Type of motorcycle: | Quad ATV & Trike, Scooter, Motorcycle, Moped & Mokick |
Units quantity: | 1 |
Manufacturer warranty: | 2 years |
Thread length: | 12.7 mm |
Thread dimensions: | M10 x 1 |
Width across flats: | 16 mm (SW16) |
Material: | Nickel |
Type: | NGK CR6HSA |
Niterra NGK SPARK PLUG EUROPE GmbH
Harkortstraße 41
40880 Ratingen DEU
Web page https://www.ngk.de/home/
Email: info@ngkntk.de

NGK spark plugs are already factory installed in 90% of all motorcycles from Japan. High-quality spark plugs have a positive effect on the consumption, the starting willingness and power development of your engine. Each manufacturer has determined the optimal spark plugs for the various vehicles in long tests, so you should always follow the factory specifications in your manual when choosing a new spark plug. Also from NGK are high quality spark plug connectors available which are suitable for most two-wheelers. At ZS2Radteile you can order NGK spark plugs and spark plug connectors in top quality and at a fair price for your motorcycle, scooter or moped quickly and easily.
